1.1 Technical specifications
Parameter
Value
Minimum - Maximum draught 11-13 Pa
Fuel consumption 2,3 kg/h
Smoke mass flow rate 11 g/s
Performance 83 %
Nominal output 7,8 kW
Power range 5 - 9 kW
Average CO concentration at 13% of O2 0,12%
Particle concentration 27 mg/Nm
3
Payload (trial) 2,1 kg
Reload interval period (trial) 50 min
Medium draft (trial) 12 Pa
Net weight 101 kg
Maximum authorized load (fuel) 3,5 kg
Reload height 200 mm
Logs length 300 mm
Minimum flue height 4000 mm
Flue duct 180 mm
Ø Air inlet 100 mm
Front safety distance 1000 mm
Side safety distance 300 mm
Back safety distance 500 mm
Primary register (trial) 5 mm open
Secondary register (trial) 35 mm open
Average temperature of smoke 144º C
Type of combustion INTERMITTENT
Flue liner NOT SHARED
Fuel NATURAL WOOD
Humidity fuel logs 12-20% - two years under cover
Certification year 2016
Certificate No.:
CEE
-
0001/16
-
1
1.2 Breakdown of delivery components
(Make sure you have all the components described below in relation to the picture on section II of the ANNEXED
document)
1.
Fireplace’s body.
2.
Flue liner connector.
3.
Heat-resistant spray paint for touch-ups.
4.
Body of the ceiling plate.
5.
Heat-resistant glove.
6.
Trim of the ceiling plate.
7.
Upper baffle plate to adjust draught.
8.
Bag with screws and anchors.
9.
Aluminium ring to connect.
10.
The body of the telescopic ceiling plate.
11.
Fixative of the aluminium ring.
12.
Tool for handling registers and opening door.
13.
Metal clamp.
14.
Exterior air inlet cover.
15.
Bag with metallic anchors.
16.
Cleaning cloth.
17.
Envelope with 3 documents: specifications, installation and operation manual, and Guarantee sheet.
1.3 Diagram of the equipment's measurements
See the ANNEXED document, section I, page 1.
1. SPECIFICATIONS
