Rocker 300 - Vacuum Pump and Compressor Diagram (Rocker 430)

5
(2) Vacuum Pump and Compressor
Position
1
2
3
4
5
6
Position
7
8
9
10
11
12
Designation
Power Switch
Air Outlet (Pressure Side)
Handle
Air Inlet (Vacuum Side)
Vacuum Gauge
Prote
TM
Filter Cartridge
Designation
Moisture Trap
Vacuum Regulator
Pressure Gauge
Filter Cartridge
Moisture Trap
Pressure Regulator (Drain Valve)
* The reference point of both vacuum and pressure gauges is atmospheric pressure.
2
431
5
9
10
11
12
6
7
8
Rocker 430
