3
Specications
Model TMS6RG TMS6SG TMS5
Nominal Diameter - inch
(mm)
6.5
(165)
6.5
(165)
5.25
(133)
Description 2-Way 2-Way 2-Way
Nominal Impedance (Ohms)
Frequency Response (Hz)
65-20kHz 65-20kHz 65-20kHz
Voice Coil Diameter - inch
(mm)
1.4
(35.6)
1.4
(35.6)
1.4
(35.6)
Power Handling - Watts
(RMS/Peak)
75/150 75/150 65/130
Fs - Free Air Resonance (Hz) 86.5 86.5 86.5
Qts 0.52 0.52 0.58
Vas - cu. ft.
(Liter)
0.198
(5.6)
0.198
(5.6)
0.191
(5.4)
Sensitivity (1W/1M) 91dB 91dB 90dB
Sensitivity (2.83V/1M) 94dB 94dB 93dB
Xmax - inch
(mm)
0.19
(3.0)
0.19
(3.0)
0.19
(3.0)
Mounting Diameter
5.0
(128)
5.0
(128)
4.6
(116)
Mounting Depth
2.1
(53)
2.1
(53)
2.0
(52)
Grille/Trim Ring YES YES YES
See page 4-6 for additional dimensions
CEA 2031
Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards. This means your speaker has the capacity to
handle power under continuous demand, not instantaneous power handling that over time can damage voice coils.
VERIFIED WITH KLIPPEL
To adorn the ‘Verified with Klippel’ mark, the qualifying company’s loudspeaker engineering personnel must be trained and certified by
Klippel prior to using the three separate Klippel systems to design, develop and test. Rockford Fosgate has made the investment in Klippel to
deliver the best possible speakers and subwoofers to their customers.
