Twin Qty. Full Qty. Queen Qty.
A1 Left Frame Bar (with pivot point) 1 1 1
A2 Right Frame Bar (with pivot point) 1 1 1
B Front and Back Frame Bar 2 2 2
C Short Center Frame Support 2 2 2
D Interior Frame Support 4 4 4
E Long Center Frame Support 1 1 1
F Frame Joint Bracket 4 4 4
G1 Piston 2 2 2
H Mattress Support 2 2 2
I Mounting Plate (Left and Right) 2 2 2
J Saddle Locking Plate 2 2 2
L Door Bracket 8 16 16
M Leg (Left and Right) 2 2 2
N Foot Bar (two pieces) 1 1 1
O Slat 40 40 42
P Slat Cap 40 40 42
Q Double Slat Cap 20 20 21
R Wrench 1 1 1
S2 #5 Allen Key 1 1 1
PARTS LIST
B
A1
C
D
I
HH
GG
N
H
M
E
L
F
P
Q
O
A2
N
