drilling or driving at 1 or 2 speeds. A slide switch is
located on top of the drill to select either 1 or 2 speed.
When using the drill in the 1 speed range, the speed
will decrease and the drill will have greater power and
torque. When using the drill in the 2 speed range, the
speed will increase and the drill will have less power
and torque.
Gear I
Low speed range: for screwdriving or working with
large drilling diameter
Gear II
High speed range: for working with small drilling
diameter.
WARNING: To prevent gear damage, always
allow the chuck to come to a complete stop
before changing the direction of rotation or the two-
speed gear control.
5. CHUCK ADJUSTMENT (See Fig. G)
To open the chuck jaws rotate the front section of the
chuck. Insert the drill bit between the chuck jaws and
rotate the front section in the opposite direction. Ensure
the drill bit is in the center of the chuck jaws. Finally,
rmly rotate the front chuck section in the opposite
directions. Your drill bit is now clamped in the chuck.
6. TORQUE ADJUSTMENT (See Fig. H)
(Screw driving force of your drill driver)
The torque is adjusted by rotating the torque
adjustment ring. The torque is greater when the torque
adjustment ring is set on a higher setting. The torque
is less when the torque adjustment ring is set on a
lower setting.
Make the setting as follows:
1 - 4 for driving small screws
5 - 9 for driving screws into soft material
10 - 18 for driving screws into soft and hard material
for heavy drilling
7. DRILLING
When drilling hard smooth surfaces, use a center
punch to mark the desired hole location. This will
prevent the drill bit from slipping off center as the hole
is started. Hold the tool rmly and place the tip of the
bit at the point to be drilled. Depress the switch trigger
to start the tool. Move the drill bit into the work-piece,
applying only enough pressure to keep the bit drilling.
Do not force or apply side pressure to elongate a hole.
WARNING: When drilling in metal, only use
HSS drill bits in good condition. Always use a
magnetic bit holder when using short screwdriver
bits. When screw-driving, apply a small quantity of
liquid soap or similar to the screw threads to ease
insertion.
8. USING THE SIGHT LIGHT
The sight light allows you to keep a clear view under
less illuminated circumstances. To turn on the light
simply press the on/off switch. When you release the
on/off switch, the light will be off.
9. HOW TO USE THE BELT CLIP (See Fig. I1 I2)
Screw the BELT CLIP (9) on the tool with the screw
provided in the plastic bag. The BELT CLIP can be
hooked on your belt or pocket, etc.
10. DISPOSAL OF AN EXHAUSTED BATTERY PACK
To preserve natural resources, please recycle
or dispose of the battery pack properly. This
battery pack contains lithium batteries. Consult
your local waste authority for information regarding
available recycling and/or disposal options. Discharge
your battery pack by operating your drill, then remove
the battery pack from the drill housing and cover the
battery pack connections with heavy duty adhesive
tape to prevent short circuit and energy discharge. Do
not attempt to open or remove any of the components.
11. OVERLOAD PROTECTION
When overloaded, the motor comes to a stop. Relieve
the load on the machine immediately and allow cooling
for approx. 30 seconds at the highest no-load speed.
12. TEMPERATURE DEPENDENT OVERLOAD PROTECTION
When using as intended for the power tool cannot be
subject to overload. When the load is too high or the
allowable battery temperature of 75°C is exceeded,
the electronic control switches off the power tool until
the temperature is in the optimum temperature range
again.
13. PROTECTION AGAINST DEEP DISCHARGING
The Li-ion battery is protected against deep
discharging by the “Discharging Protection System”.
When the battery is empty, the machine is switched off
by means of a protective circuit: The inserted tool no
longer rotates.
