2.4.2 Selective Locomotive Stop
The selective locomotive stop only stops the locomotive currently being controlled by the WLANmaus
Input Display message Comment
Press the -key and STOP-key at the same
time. The locomotive stops immediately, the
standstill symbol “II” (and the last direction of
travel) is shown on the display screen.
Note: This type of emergency stop is only indi-
cated by the last direction if an additional Lok-
maus 2 or R3 with lights is connected.
The locomotive stop is released by turning the controller, the locomotive starts to move again.
2.5 Turnout control
You can use the WLANmaus to control up to 2,048 digital turnout drives with genuine turnout ad-
dresses without having to use up a locomotive address (as is the case with the Lokmaus 2 /R3). To do
so, you can switch to turnout mode and back at any time by pressing the “Locomotive /turnout” key.
The last turnout used is always shown.
In addition to turnouts, it is also possible to switch other digitally controllable components such as
uncoupling tracks, signals, etc.
Drive mode is not interrupted in turnout mode. So the drive symbols of the last used locomotive
are shown on the display. However, the last locomotive to be active can be controlled using the
controller and an emergency stop can also be triggered.
Input Display Comment
When calling up turnout control for the rst
time, set of turnout 1 appears. In this case, as
with every other set of turnout called up for the
rst time, the complete turnout symbol appears
at the top right.
Note: The drive symbols are from the last
used locomotive, so there can be a difference
between the shown example and your situation.
You use the function keys to enter the turnout address and the arrow keys to switch the drive to set
the turnout to “straight-on"
(left arrow key) or “branch-off" (right arrow key).
Operation - Driving and Switching
