2. Using only one interface cable at a time, select the interface port you wish to use on your computer. When using FireWire, connect one
end of the FireWire cable to the appropriate FireWire port (FW800 or FW400) of your computer and then the other end to the FireWire port
in the Lancer LX. When using USB, connect the USB cable to the USB ports of your computer (or via Power Hub that is connected to your
computer) and then the other end to the USB port in the Lancer LX. Upon connection, a Blue light on the Lancer LX drive will turn ON
4. The Hard drive is preformatted for Plug-and-Play operation. After a few seconds a Rocstor HD icon will show on “My Computer” folder
under the Windows OS. Under the Mac OS, the Rocstor HD icon will appear on the “Desktop.”
5. Click (double click) on the Rocstor HD icon to access the drive.
* You may also refer to the Rocstor website to view or download a full version of the
Lancer LX
manual. www.ROCSTOR.com
Page \ 3
ROCSTOR | LANCER LX quick installation guide
Connecting the Drive
1. Turn ON your computer and wait until it fully boots up to load all programs.
2x FireWire
800
USB
3.0
FW800
FW 800
USB 3.0
(Daisy Chain Optional)
To Next Page
