RODEC /
2
TABLE OF CONTENTS
- Specifications - 2 -
- Safety instructions - 3 -
- Installation of the mixing panel - 3 -
- Frontpanel, switches and control - 3 -
- Connections - 4 -
- Operating instructions - 5 -
- Subsonic filter - 5 -
- Pictures on cover - 21 -
SPECIFICATIONS
Inputs Input sensitivity Signal/Noise Ratio Remarks
PHONO 2-3
LINE 1-4 + 1B (BX-9),
1-6 + 1B + 4B (BX-14)
MIC symm. 4 (BX-9),
5 + 6 (BX-14)
2.3mV/50kΩ
220mV/50kΩ
3.5mV/3.3kΩ
< -77dB
< -90dB
< -85dB
RIAA correction
Outputs
Master 1-2 assymm.
Recording
Aux
Phones
1.55V/10kΩ
500mV/10kΩ
775mV/10kΩ
12V/600Ω
Subsonic filter
Phones 200-600Ω
- Tone controls: Bass +/-13dB @ 100Hz
Middle +/-13dB @ 1kHz
High +/-13dB @ 10kHz
- Subsonic filter: -25dB @ 10Hz
- Power source: Panels are leaving the factory on: 230V / 50Hz-60Hz
on request: 100V-117V / 50Hz-60Hz
- Fuse: T500mA
- Power consumption: OFF=2.0VA ON=21.2VA (BX-9), 23.4VA (BX-14)
- Approbation: CE-approved
- Dimensions: Front: 482mm x 266mm (19” x 6HE)
Chassis: 444mm x 254mm x 120mm
- Weight: 5.72kg (BX-9), 6.02kg (BX-14)
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL BX-9
SERIAL NUMBER …………………………… (on the back of the set)
MODEL BX-14
SERIAL NUMBER …………………………… (on the back of the set)
Please give model and serial number when you request info.
Thank you very much for purchasing the RODEC mixing panel BX-9 / BX-14.
This mixing panel is a topline-mixing panel, capable of outstanding performance in combination with
high-grade systems.
