SAFETY INSTRUCTIONS
1) Do not expose the set to rain or water. Do not spill liquid or insert (metal) objects inside the
set. Rain, water or liquid such as cosmetics as well as metal, may cause electric shocks,
which can result in fire or shock hazard. If anything gets inside, unplug the power cord.
2) Frayed cords and broken plugs may cause a fire or shock hazard. Do not damage the power
cord. When removing the power cord from wall outlet, be sure to unplug by holding the plug
attachment and not pulling the cord.
3) Do not open the set, there are no serviceable parts inside.
Only qualified service technicians can service inside your set.
4) Operate the set only from a power source, which is indicated on the rating label at the back of
the set.
5) Do not use chemical products to clean the set. Do not use contact spray or other products in
the faders. The contact spray can damage the faders.
INSTALLATION OF THE MIXING PANEL
1) The set can be used in every position.
2) Don’t place the set into direct sunlight, or in a warm moist or dusty place.
3) To avoid disturbances, do not place the set in the neighbourhood of disturbing apparatuses.
FRONTPANEL, SWITCHES AND CONTROL
1) Power switch
Controls the supply of AC power to the set. One push turns the mixing panel on, a second
push turns it off. It remains in a stand-by mode.
2) Power "ON" on indicators
These indicators light up when the power is on.
3) VU meters
The two VU meters indicate the PFL signal.
4) Phones output
Output for high level headphones monitoring. With the PFL switches (7) the connected audio
sources (in split mode) can be displayed without manipulating the output signal (Headphones
200-600Ω).
5) Phones control
This button is used to adjust the volume of the headphones.
6) Phones-select potentiometer
With this potentiometer, the signal for the headphones output can be selected. When turned
completely to the left, the signal selected with the channel PFL-switches (7) appears on the
headphones. When turned completely to the right, the mix-signal appears on the headphones.
In between it results in a mix of the PFL-signal and the mix-signal.
7) PFL switches
With these switches you can select the different input sources that you will listen to with the
headphones.
