8) Input selector
This switch is used to select the input signal.
9) Level adjuster
These controls are used to adjust input levels of the different inputs.
10) Equalizer controls
This is used to regulate the degree of treble, middle and bass in the sound.
11) Channel faders
Volume control for every input.
12) Crossfader
With this fader you can easily fade over between channels 2 and 3 for BX-9 and channels 1-2
and 3-4 for BX-14. When the knob stands completely to the left, the signal of channel 2 on BX-
9 and channels 1 and 2 on BX-14 will appear on the output. When the knob stands completely
to the right, the signals of channel 3 for the BX-9 and channels 3 and 4 for BX-14 will appear
on the output.
13) Balance
The balance between the amount of sound on the left and on the right is adjusted by using this
knob. When it is set to the center position, the gain is the same for the left and the right
channel.
14) Master output faders
Volume controls final output of mixer towards slave- or integrated amplifers.
CONNECTIONS
A) PHONO input
Phono input with a sensitivity of 2.3mV and build in RIAA correction.
B) Ground
If the recordplayer has a ground wire, connect it to the ground terminal.
C) LINE/LINE B input
Input with a sensitivity of 220mV. To connect different apparatuses such as a CD-player,
tuner, tape recorder, mini disc, cassette recorder or (HIFI) video recorder.
D) Microphone input
Balanced microphone input with a sensitivity of 3.5mV. Combined connector XLR + JACK.
The JACK connector can also be used for unbalanced microphones.
E) Effects IN/OUT
Input and output to connect effect apparatus to the microphone channel. If there is no plug in
the JACK, the microphone channel works normally, if there is a plug inserted in the JACK, the
internal link is interrupted. The sensitivity of this IN/OUT connection is 220mV.
F) Recording outputs
Outputs to connect cassette recorder, MD-recorder or (HIFI) video recorder to make
recordings.
G) AUX output
Output for different apparatuses as integrated amplifiers, mixers or recorders.
The output level is 775mV.
H) Master output 1 Assymetrical
Assymetrical output to connect a power-amplifier. The output level can be manipulated with
the master fader 1 (14) from 0 to maximum (1.55V).
