Roger Technology Swing Gate Brushless B70-2DCHP Control Panel
Quick Start Guide Extended Mode
5
Step 8)
Insert the radio card into the slot on the main PCB.
Push the P1 button once on the radio card, followed by the button on your remote fob that you want to open the
gate fully with. Push the P2 button once on the radio card, followed by the button on your remote fob that you
want to open the gate partially. (PEDESTRIAN)
(Deleting all codes.)
Press the receiver buttons P1 and P2 simultaneously for 4 seconds: 5 fast blinks of the two LEDs indicates total erasure of stored codes.
NOTE: it’s recommended to delete all codes at the first installation before starting storing codes.
Step 9)
Test the system
You can now test run the system with the fob.
If necessary reduce the impact force level with the menus 30 to 33 in the parameters. These settings are explained in
the manufacturers B70/2DCHP manual.
Step 10)
Add in the necessary safety photocells, safety edges and other devices applicable to your installation as explained in
the manufacturers B70/1DCHP manual
Step 11) Enabling Automatic Closing.
Change the parameter A2 to any number other than 00. Eg. 05 would make the gate auto-close and re-attempt a
further 5 times before remaining open.
The pause time for auto-closing is pre-set to 30 seconds. Use the parameter 21 to change the time.
