3.2.1. Reader Operating Modes
The factory new reader is pre-configured for RACS address ID=0 however whenever required it
can be changed using Memory Reset procedure. There are following operation modes available for
the PRT-LT series reader:
Code Operating mode Description
000 Online mode: RACS address ID=0
Reader operates as a slave unit connected to the host
controller that requires RACS data transmission format.
001 Online mode: RACS address ID=1
002 Online mode: RACS address ID=2
003 Online mode: RACS address ID=3
020
Online mode: Magstripe Reader operates as a slave unit connected to the host
controller which requires Magstripe data transmission
format, keys are not transmitted.
021
Online mode: Magstripe UNITEK Reader operates as a slave unit connected to a host
controller which requires Magstripe data transmission,
keys transmitted as single digits, format is compatible with
specification of UNITEK controllers (with transmission of
PIN-s).
10x Online mode: 26 bit Wiegand
Reader operates as a slave unit connected to the host
controller that requires relevant Wiegand data
transmission format.
11x Online mode: 34 bit Wiegand
12x Online mode: 42 bit Wiegand
13x Online mode: 66 bit Wiegand
14x
Online mode: 32 bit Wiegand
(no parity)
15x
Online mode: 32 bit Wiegand
reverse (from LSB to MSB, no
parity)
Note: For Wiegand data formats the second digit of the operating mode code (marked as X) specifies the
method which reader employs when transmitting PIN-s or keys. For details regarding methods of PIN
transmission refer to table below.
