Roger PRT12LT - Page 8

PRT-LT Series Readers fv1.25 Rev. G 2016-10-08
Page 8 from 17
Table A: 8-bit key coding
Key HEX BIN
0 F0 11110000
1 E1 11100001
2 D2 11010010
3 C3 11000011
4 B4 10110100
5 A5 10100101
6 96 10010110
7 87 10000111
8 78 01111000
9 69 01101001
* 5A 01011010
# 4B 01001011
F1 3C 00111100
F2 2D 00101101
Table B: 4-bit key coding
Key ASCI BIN
0 0 0000
1 1 0001
2 2 0010
3 3 0011
4 4 0100
5 5 0101
6 6 0110
7 7 0111
8 8 1000
9 9 1001
* A 1010
# B 1011
