HS07
RC01
Specification:
ITEM HS04 HS07
Connector HDMI Type A
Input / Output
HDMI (Input) x 4、
HDMI (Output) x 1
HDMI (Input) x 7、
HDMI (Output) x 1
Color depth 12 Bits/Color (Data rate up to 2.25Gbps)
Resolutions 1080p (Max)
Function Button Button x 8 Button x 11
Power Supply DC 5V 1AMP Regulated ( External )
Power Consumption 300mA ( Max ) 600 mA (Max)
Temperature
Operation: 0 to 55℃, Storage: -20 TO 85℃, Humidity: up to 95%
Dimensions mm 253 x 138.5 x 40
Weight g 770 775
ITEM RC01
PC (RS-232) DB9 Connector (Female)
Console 4 PIN Female Header
Distance 15M (max)
Baud Rate 115200 bps (max)
Power Source (DC) From Terminal +5V
Power Consumption 50 mA (max)
Temperature
Operation: 0 to 55℃, Storage: -20 TO 85℃, Humidity: up to 95%
Dimension mm 57.5 × 33.5 × 16.8
Weight g 22
PC RC01
