Roketa GK-06 - 1. Performance, Technical Parameters and Structure of Go Kart; 1.1 Performance and Specifications; 1.2 Component Location and Structure

3
1. The performance, Technical parameter and Structure of Go Kart
Model GK-06 Displacement 244cc
length 2620mm (106.3 inches) Bore×stroke 72×60mm
Width 1820mm (70.9 inches) Compression ratio 10:1
Height 1600mm (66.9 inches) Rated power 12.5kw/7500±500r/min
Wheelbase 1980mm (78.7 inches) Max torque 17.6N.m/5500r/min
Front wheel track 1600mm (61.8 inches) ignition CDI
Rear wheel track 1460mm (56.7 inches) lubrication Forced lubrication & splash lubrication
Ground clearance 290mm (8.3 inches) Start Electronic
Max speed 50km/h Gear shift hand
Braking length <7m (30km/h) Spark plug C7HSA
Climbing capacity ≤45· Gross weight 535kg
Net weight 360kg Fuel type RQ93 (unleaded)
Loading capacity 2person or 175kg Engine oil type SAE15W40(summer) SAE10W/30(winter)
Oil mass 1.0 L Front wheel
Gear box oil 0.18 L
suspension
Rear wheel
Rocker arm ,independent suspension
Oleo-pneumatic damping shock absorber
Fuel tankage 11 L Front wheel
Cooling liquid 1.19L
Brake
Rear wheel
Hydraulic disc brake ,right foot control
Engine type Single cylinder,4 stroke, liquid cooling Front wheel 25×8-12
Battery 12V12Ah
Tire
Rear wheel 25×10-12
Head light 12V/55W Front wheel 200kpa
Fuse 15Ah
Tire pressure
Rear wheel 200kpa
Rear light and brake light 12V 5W/10W
2 Component location and structure
1.1Performance and Specifications
