Roland ep-97 Service Notes

3
EP-77
Dec, 1999
EXPLODED VIEW
9
2
2
8
1
3
5
6
10
12
13
13
11
14
7
4
No.
Part No. Description
1
7711507000 VARN+SILK. TOP CABINET
2
3
K2198107 PLASTIC MUSIC REST
4
7711508000 VARN+SILK. SOCKET SUPPORT
5
7711501000 MAIN PCB ASSY
6
7
7711503000 BEAT & TEMPO PCB ASSY
8
7711504000 HEADPHONE PCB ASSY
9
10
11
K2268157 VIBRATION DAMPER PL 45 (SHORT)
12
7697607000 76-KEYBOARD ASSY TP/9P
13
14
SPEAKER 4 OHM 120.20B/FX
FELT WASHER I/D 7 E/D 13 TH. 1,5
K2418103
K2248150
7711505000
JACK PCB ASSY
K2268156
K2248125
7711502000
ANTIDUST COVER PL 45
GRILL F/LOUDSPEAKER
CONTROL PCB ASSY
A
A
B
B
B
C
C
C
G
C
D
E
F
A
B
C
D
E
F
G
J2289112
J2289115
J2289108
J2289125
J2139102
J2289102
J2289113
(SCREW)
SCREW 3,5x13 TCTC H.8 BRUN.
SCREW 3,5x9,5 TC PR TFR H.8
SELF LOCK. SCREW M3x10 TCTC H.6
SCREW 2,9x10 TCTC PR TROP
TOOTHED WASHER I/D 3
SELF TAP. SCREW 2,9x10 TCTC
NUT 3MA H.3
