EP-77
Dec, 1999
6
WIRING, CABLE
# K3468211 2P CABLE (100) -1C From CN4 on JB to SPEAKERS
K3468159 16P FLAT CABLE ASSY (72) -2C From CN5 on MB to CN1 on LCB
K3468162 20P FLAT CABLE (56) -2C From CN6 on MB to CN2 on RCB
# 7711509000 4P CABLE ASSY (18) -2C P.2 D/D From CN4 on MB to CN103 on BTB
# 7711510000 2P COAXIAL CBL ASSY (20) -2C P.2 D/R From CN6 on JB to CN102 on CB
# 7711511000 7P CABLE ASSY (68/60) -2C P.2 From CN3 on JB to CN5 on PB + Left Speaker
# 7711512000 7P CABLE ASSY (28) -2C P.2 D/R From CN2 on MB to CN2 on JB
# 7711513000 10P CABLE ASSY (24) -2C P.2 D/R From CN3 on MB to CN101 on CB
# 7711514000 11P CABLE ASSY (16) -2C P.2 D/R From CN8 on MB to CN1 on JB
SCREW
J2289122 SCREW 2.2X6 TC TC BRUN 2
J2289102 SELF TAP.SCREW 2.9X10 TC TC 7
J2289125 SCREW 2.9X10 TC TC PR TROP 36
J2289131 SELF TAP.SCREW 3.5X16 TCTCPRBZ 37
J2289118 SCREW 2.9X16 TC TC PR BRUN 2
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 2
J2289109 SELF LOCK.SCREW M4X14 TCTC H. 9.5 2
J2289115 SCREW 3.5X9.5 TC PR TFR H.8 14
J2289112 SCREW 3.5X13 TCTC H.8 BRUN 4
J2289113 NUT 3MA H.3 2
PACKING
K2638171 RIGHT POLYST. END-SIDE EP-75 1
K2638172 LEFT POLYST. END-SIDE EP-75 1
K2678105 CARTENE ENVELOPE HD 140X57 1
K2678106 POLYETH.ENVELOPE 4OX55 1
# K2618213 OUTER PACKING EP-77 1
MISCELLANEOUS
K2268128 RED FELT MM. 1250X7X1 1
# K2268156 ANTIDUST COVER PL45 EP-77/97 1
# K2268157 VIBRATION DAMPER PL45 (SHORT) EP77/97 1
# K2248150 FELT WASHER I/D 7 E/D 13 TH.1.5 3
1342982301 POWER SUPPLY SOCKET HOLDER N°2 1
J2139102 TOOTHED WASHER I/D 3 2
K2168102 SPACER FOR LED H.2.8 D.E. 5.5 5
K2168105 SPACER F/LED H.12 HEX. 1
# K2168114 LED SPACER H.1.8 E.D.9 1
J2359101 SPACER 3M ART. SJ5012 4
ACCESSORIES
# K6018361 O.MANUAL (IT/E/D/SP/OL) EP-77/97 1
7710610000 PEDAL DP-2 1
K2448106 POWER ADAPTOR ACO 230V 12V 1A for (230V) 1
K2448107 POWER ADAPTOR ACO 230VE 12V 1A for (230VE) 1
K2448109 POWER ADAPTOR ACO 120V 12V 1A for (117V) 1
PARTS LIST STAND KS-EP-77
CASING Q.ty
K235810101 FOOT F/SIDE PANEL (STAND) 2
K1128121 RIGHT SIDE FRAME (2ND VERSION) 1
K1128122 LEFT SIDE FRAME (2ND VERSION) 1
K1148140 REAR CROSS BAR 1072 MM. (2ND VERSION) 1
SCREW
J2289186 SCREW 3.5X16 TCPR TFR H.8 BRUN 4
J2329101 SCREW DRIVER TYPE 2 1
J2329107 JOINT BOLT ASSY 4
PACKING
K2638134 RIGHT POLYST. END-SIDE 1
K2638135 LEFT POLYST. END-SIDE 1
K2638136 MIDDLE POLYST. END-SIDE 1
K2668102 CARTON PLATE MM. 1440X440 1
# K2618215 OUTER PACKING KS-EP-77 1
MISCELLANEOUS
K2128113 KEYBOARD HINGE CHASSIS 2
ACCESSORIES
# K6018362 ASSEMBLY INSRUCTIONS KS-EP-77 1
