Roland FANTOM-08

Editing
21
Editing the Eects
The arrangement and signal paths for each eect are as shown below. Select the eect to match your needs, and then edit its settings.
Here we’ll explain how to edit the tone eects (MFX).
SCENE
FANTOM-0x Block Diagram
FANTOM-0x Block Diagram
Master FX
IFX 1
Insert Eect 1
MFX
Multi Eect
Zone EQ
IFX 2
Insert Eect 2
M. COMP
Master Comp
M. EQ
Master EQ
TFX
Total Eect
ZONE 1–16
ZEN-Core
PARTIAL
Ó
PARTIAL EQ
Drum Kit
Inst
Ó
KIT PTL EQ
COMP
x 6
for Drum kit
VTW
Virtual Tone Wheel
* Zone 2 only
SN-A
SNAP, SNEP
Chorus Send
Reverb Send
Chorus
Reverb
MIXER
MAIN Output
SUB Output
5
For details on the IFX1/2, Chorus, Reverb and Master FX, see the “Parameter Guide” (PDF).
Editing the Tone’s Eect
(MFX)
Here’s how to edit the tone’s eect (MFX).
1.
Press the [MENU] button.
The MENU screen appears.
2.
Touch <EFFECTS EDIT>.
The EFFECTS EDIT screen appears.
Turning the MFX on/o
1.
In the screen, touch <MFX> to turn it on/o.
Editing the MFX parameters
1.
In the MFX section, touch <EDIT>.
The EFFECTS EDIT ZOOM screen appears.
2.
In the MFX section, touch <EDIT>.
The MFX EDIT ZOOM screen for MFX appears.
