Roland PC-70 - Panel Descriptions

9
Panel Descriptions
fig.Panel.e
[20] MIDI OUT Connector
[22] AC Adapter Jack
[23] POWER Switch
[21] SUSTAIN SWITCH Jack
[5] DATA ENTRY Slider
[3] MIDI / SELECT Button
[2] OCTAVE UP / DOWN / STANDARD Buttons
[1] PITCH / MODULATION Wheels
[6] MIDI CHANNELS (1 to 16)
[7] AFTERTOUCH
[8] VELOCITY
[10] REVERB LEVEL
[9] CHORUS LEVEL
[11] PANPOT
[12] VOLUME
[13] CC SELECT(Select Control Change)
[14] CC32
[15] CC00
[16] PC(Program Change)
[17] NUMERIC ENTRY Section (0 to 9)
[18] CANCEL
[19] ENTER
[4] DISPLAY(LED)
