Assembling goes as follows:
• Make sure to not lose the small pre-mounted spacer ring X
placed in-between the clamps of the mounting clamp. It
should always remain on the long Allen screw with flat head.
• Fix the mounting clamp as high as possible on the frame,
with help of the Allen key (figure 4). The plastic wing nut
must point outwards.
• Tighten the screws firmly.
• You can now place the umbrella pole in the umbrella clamp
from above and tighten the plastic wing nut (figure 4).
• One of the two adjusting rings Y (figure 5) can be placed on
the umbrella pole for setting the umbrella to the desired
height. You can choose from a maximum of three different
heights.
• The distance between the tip of the umbrella and the ground
should be at least 3-5 cm when the umbrella is folded.
• Place the second adjusting ring Y under the mounting
clamp. This secures your umbrella on the bottom.
• Tighten the screws again after two days.
Figure 5: Attaching the adjusting
ring Y.
