Romstal VISION - Installation

38
INSTALLATION
7
panels
Pallet contents:
collector
document envelopes containing instruction manual
9
-
9
STORE IN A DRY PLACE AND DO NOT EXPOSE TO DIRECT SUNLIGHT
UNTIL THE TIME OF INSTALLATION! -
Installation
8 HANDLING
Data label
GROSS AREA : 2.00M2
DIMENSIONS : 1235x1625x85mm
MAX OPER. PRESSURE : 10 Bar
STAGNATION TEMPERATURE : 180 °C
WEIGHT EMPTY : 29.15kg
PRODUCTION DATE : 2022
MAX GLYCOL CONCETRATION: 53%
Made in E.U
FLAT SOLAR PANEL
APERTURE AREA: 1.90M2
2201262500002382
SERIAL NUMBER
ABSORBER CAPACITY: 1.38 L
ABSORBER AREA: 1.90M2
A
A
A
A
9
-
0
-
0
