KNOW YOUR PRODUCT KNOW YOUR PRODUCT
1. Saw arm
2. Release knob
3. Operating handle
4. Upper fixed blade guard
5. Rotating blade guard
6. Guard retraction arm
7. Bevel lock
8. Bevel scale
9. 45° Bevel adjustment screw
10. 0° Bevel adjustment screw
11. Fence
12. Miter table
13. Miter scale
14. Table insert (kerf plate)
15. Miter lock
16. Switch trigger
17. Spindle lock button
18. Blade bolt cover
19. 6mm Hex key
20. Dust extraction port
21. Dust extraction port cover
22. Dust bag (not shown)
Parts list
6
3
20
5
16
4
18
15
13
14
12
11
1
2
8
10
21
9
7
19
17
22
