6 – Electrical and Thermal Characteristics
Signal
Parameters
Min.
Máx.
Unit
VS
Supply Voltage
10.8
14.7
V
IS
Supply Current
-
8.4
A
I Stand by
Current Standby
-
0,001
A
V EXT
Supply Voltage for External Sign for the
Siren
-
1.8
V
V IN
Supply Voltage for other Inputs
3.9
14,7
V
V Radio
Supply Voltage for Radio Input
-
5
Vpp
I-Out1 - 8
Output Current – Outputs 1 to 8
-
250
mA
V OUT SIR
Output Siren Voltage (Speaker of
50W)
-
44
Vpp
Output Siren Voltage (Speaker of
100W)
-
69
P OUT SIR
Output Siren Power
-
50 (8Ω)
W
RMS
-
100 (11Ω)
T Storage
Storage Temperature
-20
80
ºC
Table 3: Electrical and Thermal Characteristics
7 - Compatibility
IS2100-M G-II is a device compatible with all Rontan S-Series lightbars. It also has analog signal
outputs to command third party lightbars.
8 - Installation
 The installation of this equipment requires that the installer has a good knowledge of
automotive procedures and electrical systems.
 Before starting the installation on your device, it is important to read these instructions for the
safe/correct installation and operation of this product.
9 – Harness Cable Connector
IS2100-M G-II comes with the harness cable connectors as shown on Figure 3, described as General
Connection. It is extremely important to follow the instructions in Table 3.
Connection
Cable
Section
Supply
14 AWG *
1,5 mm² *
Siren Output
14 AWG
1,5 mm²
Connector 1
20 AWG
0,5 mm²
Connector 2
20 AWG
0,5 mm²
Table 4: Connection Wire Gauge
* For another type of conductor, calculate the length considering in a current of 8.4 A and a maximum voltage
drop of 0.2 V (positive and negative wires).
