STEP 2:
MEASURE THE OUTSIDE
DIMENSION AT THE FLOOR
AND MAKE SURE IT IS 64 3/4”
STEP 3:
USING SPACER BLOCKS IF
REQUIRED AS SHOWN ON PAGE 10, USE
YOUR DRILL-GUN WITH A #2 PHILLIPS
HEAD TO DRIVE K119 SCREWS AT A 10
DEGREE DOWN-ANGLE TO ATTACH
METAL FRAME TO THE WALL (DIAGRAM
ON PAGE 10).
STEP 1:
USE A PENCIL AND STUD-FINDER
TO MARK THE CENTER OF A
STUD ON EACH SIDE. THE STUD
PLACEMENT DOES NOT NEED TO
BE LATERALLY SYMMETRICAL.
(WE WILL USE THESE MARKS IN A
LATER STEP.)
STEP 1
USE A STEP LADDERTHAT WILL
SAFELY ALLOW YOU TO
MEASURESTUD POSITIONS
Marking Studs, measuring width one last time,
and driving long screws into the base plate.
