Setting up the Bed Case – part C

Step 1: From Box 2, find the Headboard panel and position the headboard to the side panels using guide dowels.

Step 2: Use K110 bolts and K111 barrel nuts from bubble pack 2 to connect the headboard to the side panels.

Headboard

Zip line face down

away from the wall

Headboard

BACK

K160

Allen

wrench

K110

bolt

K111

nut

Step 1

Step 2

Headboard

FRONT

dowel
