ROOTS RootsScrub E4550 ES - Page 9

9
RootsScrub E4550 ES
16. Filter for water pump
17. Lever to rotate brush head
18. Suction hose
19. Water spray nozzle
20. Accessories attachment point
21. Water manifold
22. Electrical float switch
23. Float for vacuum shut-off
16
17
18
19
20
21 22
23
KNOW YOUR MACHINE
Machine direction
Drive side (DS)
Idle side
(IS)
