S i z e HxWxD - 12.5 x 4.75 x 2.5”(319mm x 120mm
x 64mm) Unit - 2lb. 12oz lbs. (1.25 kg) Power
adapter - 0.625 lbs. (.28 kg)
Supported ETC Source 4
Fixtures Altman 1KL
Supported Standard B Size - 2.5” (64.5mm) image size
Gobo Size Maximum - 3.38” (86mm) outer diameter.
Power Supply Plug-In transformer with NEMA 1-15 Plug
120 and 240 volt versions, 50/60Hz,
6W MAX, 100/.06amps, 120/.05, 200/.03,
240/.025
Output -12VDC, 6W Maximum
Switchable Polarity
Cord Length - 52” (1320mm)
Connector - 3-pin Male DIN
VORTEX 360 SPECIFICATIONS
9
