INSTALLATION
2.1 Preliminary Instructions
Installation must be carried out by following the instructions contained in this handbook and only by
a licensed tradesman in accordance with local codes, or in absence of it, with the National Fuel
Gas Code ANSI Z223.1 or with the Natural Gas Installation Code CAN/CGA-B149.1. The
manufacturer cannot be held liable for any damage caused by faulty installation.
The place where the machine is to be installed must have aeration equal to at least that give
in Table 1.1. This is in order to supply the necessary air for combustion, to prevent reaching too
high percentages of gas and to aid evacuation of the products of combustion. The installation room
must be in conformity with the current fire regulations.
The unit must operate in a level position. Slight floor irregularities can be compensated by turning
the adjustable feet of the cooker either clockwise or counterclockwise.
Clearances from combustible and noncombustible construction are give in table 1.2.
Table 1.1 Minimum change of air in relation to the thermal power installed.
Table 1.2 Clearances from combustible and noncombustible construction.
2.2 Handling and Unpacking
To move the machine to the place of installation, use a fork lift truck. Do not drag the appliance on
the floor. Take the adhesive protection off the steel surfaces, taking care not to leave any remains
of glue, in which case, use appropriate thinner to remove them.
Model Power (BTU/hr) Air flow (m³/h)
CPG1 60000 (13.2 kW) 490
CPG2 120000 (26.4 kW) 980
CPG3 180000 (39.6 kW) 1470
CPG7/1 31000 (9 kW) 315
CPG7/2 62000 (18 kW) 630
Clearances Combustible
construction
Noncombustible
construction
Side 6.0” 0”
Rear 6.0” 0”
Floor 6.0” 0”
Ceiling 48”
