Auxiliary Mode Reference Guide
The following are brief descriptions of each of the AC-G43's
auxiliary modes. To use these features refer to "Setting the Auxiliary
Mode" on page 27.
AUXILIARY MODE 0
In auxiliary mode 0 the AC-G43 can function as a two door
controller. The auxiliary relay should be attached to the lock on the
second door. The auxiliary setting defines the door open time for
the second door. The auxiliary input should be attached to the REX
button for the second door.
AUXILIARY MODE 1
In auxiliary mode 1 the AC-G43 can function as a two door
controller. The auxiliary relay should be attached to the lock on the
second door. The auxiliary setting defines the door open time for
the second door. The auxiliary input can switch the mode of
operation of the controller between Normal and Secure Mode. By
connecting a switch timer to the auxiliary input you can for example
automatically switch the AC-G43 from Normal Mode during office
hours to Secure mode after office hours.
AUXILIARY MODE 2
In auxiliary mode 2 the auxiliary relay can function as a general
purpose timed switch that can be activated when the star button on
the AC-G43 is pressed. The auxiliary setting defines how long the
auxiliary relay should be activated. The auxiliary input can switch
the mode of operation of the controller between Normal and Secure
Mode. By connecting a switch timer to the auxiliary input you can
for example automatically switch the AC-G43 from Normal Mode
during office hours to Secure mode after office hours.
AUXILIARY MODE 3
In auxiliary mode 3 the auxiliary output is activated if the AC-G43 is
tampered, i.e. the case tamper or back tamper is triggered. The
auxiliary input can switch the mode of operation of the controller
AC-G43
Auxiliary
Mode
Auxiliary Mode Quick Reference Table
0 REX-2 Valid Code or REX-2 N.O. 01 to 99 Aux. Relay Release Time
00 Aux. Relay Toggles
1 Normal / Secure Valid Code N.O. 01 to 99 Aux. Relay Release Time
00 Aux. Relay Toggles
2 Normal / Secure Star Button N.O. 01 to 99 Aux. Relay Release Time
00 Aux. Relay Toggles
3 Normal / Secure Tamper Event N.C. 01 to 99 Aux. Relay Release Time
00 Aux. Relay activated by Tamper
4 Normal / Secure Direct Shunt N.O. 00 to 99 Shunt Time
5 Door Monitor Shunt N.C. 00 to 99 Maximum Shunt Time
6 Door Monitor Forced Door N.C. 00 to 99 Forced Delay
7 Door Monitor Door Ajar N.C. 00 to 99 Ajar Delay
8 LED Ctrl - Red Valid Code N.O. 01 to 99 Aux. Relay Release Time
00 Aux. Relay Toggles
9 LED Ctrl - Green Valid Code N.O. 01 to 99 Aux. Relay Release Time
00 Aux. Relay Toggles
Auxiliary Input
Function
Auxiliary Output
Activated On
Auxiliary Settings Aux.
Relay
(All times and delays are in seconds)
To Next Page
