Technical Specifications
AYC-E/Q/T60 Family Installation and Programming Manual 13
Environmental Characteristics
Operating Temp. Range
-22°F to 150°F (-30°C to 65°C)
Operating Humidity Range
0 to 95% (non-condensing)
Outdoor Usage
Weather-resistant, meets IP-65,
epoxy potted, suitable for indoor
and outdoor use
Physical Characteristics
Size
(Height x Width x Depth)
E: 155 x 44 x 9 mm (6.10 x 1.7 x
0.35 in.)
Q: 120 x 76 x 21 mm (4.72 x 2.99 x
0.83 in.)
T: 121 x 70 x 8 mm (4.77 x 2.76 x
0.31 in.)
Weight
E: 143 g (5.04 oz)
Q: 480 g (16.93 oz)
T: 121 g (4.27 oz)
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.
