4.7 Actuators Removal Guide
footrest
actuator red
plug
b a ck r e s t r e c l i n e
actuator white plug
fo o t r e s t li f t
actuator
24V/80mm
forwarding
actuator
24V/280mm
f o r w a r d i n g
actuator yellow
color plug
b a c k r e s t r e c l i n e
actuator（with hall）
24V/124mm
Maintenance Guide - Inner structure & installation
