2. Vertical Clearance
Check the height of the area where the lift is to be
installed. Clearance should be calculated based on the
full raised height of the lift and the height of the tallest
vehicle being lifted.
WARNING
Failure by purchaser to provide
adequate clearance could result in unsatisfactory lift
performace, property damage, or personal injury.
3. Flooring
Be certain you have the proper concrete floor to
properly handle the loaded lift. Floor should be in
generally good condition with no large cracks, spalling
or deterioration.
Minimum requirements for concrete are 100 mm
minimum depth, with steel reinforcement, cured to
3000 psi. Floor should be level within 6mm under each
platform area. No anchors should be installed within
64mm of any crack, edge, or expansion joint. There
should be no floor seam under ramp roller locations. If
these conditions cannot be met, a pad may be poured
to accommodate the lift.
Check with local building inspectors and/or permits
office for any special instructions or approvals
required for your installation.
WARNING
Failure by purchaser to provide
the recommended mounting surface could result in
unsatisfactory lift performace, property damage, or
personal injury.
4. Electrical Requirements from Customer
• 380 VAC three phase 50 Hz power for 7 full load
amps.
• 208-230 VAC single phase 50 Hz or 60 Hz power for 21
full load amps.
• All wiring must conform to all national and local
electrical codes.
IMPORTANT
Never operate the motor on line voltage
less than 208V. Motor damage may occur.
IMPORTANT
Use separate circuit for each power unit.
Protect each circuit with a time delay fuse or circuit
breaker.
WARNING
Make sure that the main power
supply is disconnected to avoid the possibility of
electrocution.
5. Safety Notices and Decals
For your safety, and the safety of others, read and
understand all of the safety notices and decals
included here.
Proper maintenance and inspection is necessary for
safe operation.
DO NOT operate a damaged lift.
Safety decals similar to those shown here are found
on a properly installed lift. Be sure all safety decals
have been placed on the control cabinet. Verify that all
authorized operators know the location of these decals
and fully understand their meaning. Replace worn,
faded, or damaged decals promptly.
WARNING
Do not attempt to raise a vehicle on
the lift until the lift has been correctly installed and
adjusted as described in this manual.
4
