Functional Description and Specifications
Disconnect battery pack from tool or place the switch in the locked or off
position before making any assembly, adjustments or changing
accessories. Such preventive safety measures reduce the risk of starting the tool accidentally.
!
WARNING
NOTE: For tool specifications refer to nameplate on your tool.
SHAFT LOCK
REMOVABLE
AUXILIARY
HANDLE
WRENCH
STORAGE AREA
INTAKE AIR
VENTS
BASE PLATE &
DEPTH GUIDE
DEPTH GUIDE
BRACKET
COLLET NUT
ON/OFF SLIDE
SWITCH
DEPTH GUIDE
LOCKING KNOB
COLLET & BIT
STORAGE AREA
INTAKE
AIR VENTS
EXHAUST
AIR VENTS
BATTERY PACK
RELEASE BUTTON
-6-
IMPORTANT: Some of the following symbols may be used on your tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and safer.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
kg Kilograms Weight
min Minutes Time
s Seconds Time
Diameter Size of drill bits, grinding wheels, etc.
n
0
No load speed Rotational speed, at no load
.../min Revolutions or reciprocation per minute Revolutions, strokes, surface speed,
orbits etc. per minute
0 Off position Zero speed, zero torque...
1, 2, 3, ... Selector settings Speed, torque or position settings.
I, II, III, Higher number means greater speed
Infinitely variable selector with off Speed is increasing from 0 setting
Arrow Action in the direction of arrow
Alternating current Type or a characteristic of current
Direct current Type or a characteristic of current
Alternating or direct current Type or a characteristic of current
Class II construction Designates Double Insulated
Construction tools.
Earthing terminal Grounding terminal
Warning symbol Alerts user to warning messages
Ni-Cad RBRC™ seal Designates Ni-Cad battery recycling
program
Symbols
0
SCSØ2TYPE3
This symbol designates that
this tool is listed by
Underwriters Laboratories.
This symbol designates that this
tool is listed by the Canadian
Standards Association.
This symbol designates that
this tool is listed to Canadian
Standards by Underwriters
Laboratories.
