Paktester -
Publication S178E
Issue 1.1 November 2000
As we are continually developing our products their design is subject to change without notice
The contents of this document are copyright and must not be reproduced without the written permission
of Rotork Controls Ltd.
THIS MANUAL REPLACES THE PAKTESTER MANUAL R5161-016 AND
RELATES TO PAKTESTERS FITTED WITH V5.0 FIRMWARE OR GREATER
Related Documents:
[1] Pakscan Master Station Modbus Interface Specification S171E
[2] Pakscan IQ Field Unit Technical Manual S172E
[3] Pakscan Integral Field Control Unit Technical Manual S173E
[4] Pakscan General Purpose Field Control Unit Technical Manual S174E
[5] Pakscan IQ Analogue Input Field Unit S164E
Abbreviations used in this document:
CA = Close Auxilliary Switch
CT = Close Torque Limit Switch
DV = Desired Value
ESD = Emergency Shut Down
FCU = Field Control Unit
FTU = Field Test Unit, - Paktester
GPFCU = General Purpose Field Control Unit
I1 = Intermediate Auxiliary Switch 1
I4 = Intermediate Auxiliary Switch 4
MV = Measured Value
NC = Normally Closed (contact)
NO = Normally Open (contact)
OA = Open Auxiliary Switch
OT = Open Torque Limit Switch
