-9-
92'8-32%0)7'6-48-32%2(4)'-*-'%8-327
-7'322)'8 8,) 409+ *631 8,) 43;)6 7396') &)*36) 1%/-2+ %2=
%77)1&0=%(.9781)28736',%2+-2+%'')7736-)7 Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
$!@
Model number RFS1000
* Rated speed n
o
11,000/min
* Max. abrasive wheel diameter 4" (100 mm) type 1
Spindle thread 5/8"-11 UNC
FIG. 1
Accessory speed rating must be equal to or greater than the tool’s speed rating. Do not
exceed the recommended wheel diameter.
For tool specifications refer to the nameplate on your tool.
SPINDLE LOCK
SWITCH
BUTTON
VENTILATION
OPENINGS
ABRASIVE
WHEEL
WHEEL
GUARD
SIDE HANDLE
GUARD
PLUG
LOCKING
LEVER
BM 2610008432 08-10:BM 2610008432 07-10 7/29/10 10:08 AM Page 9
