Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
The rated speed of the accessory must be at least equal to the maximum
speed marked on the power tool. Accessories running faster than their RATED
SPEED can break and fly apart.
NOTE: For tool specifications refer to nameplate on your tool.
Spiral Saw™
INTAKE
AIR VENTS
EXHAUST
AIR VENTS
DEPTH GUIDE
COLLET
COLLET NUT
-8-
FIG. 1
BUMP SWITCH
(ON/OF)
DEPTH GUIDE
THUMBSCREW
CORD
SHAFT LOCK
