ROTZLER TITAN TI 5 - User Manual

Questions and Answers

P
Patricia BarnesAug 6, 2025
Why is my ROTZLER TITAN TI 5 not hoisting the nominal load?
- T
  Timothy HowardAug 6, 2025
  Why is my ROTZLER Winches not hoisting the nominal load? The possible causes are: * Insufficient hydraulic supply pressure. To fix this, connect pressure gauges to the pressure connections of the motor and measure the hydraulic pressure. Correct the pressure if required. * Faulty winch motor. In this case, you should repair or replace winch motor. * Oil operating temperature too low. You can solve this by warming up the hydraulic system.
Z
Zachary SmithAug 17, 2025
What to do if my ROTZLER TITAN TI 5 Winches does not reach nominal speed?
- B
  Benjamin ShafferAug 17, 2025
  What to do if my ROTZLER Winches does not reach nominal speed? This can happen due to: 1. Insufficient hydraulic supply volume flow. Use a flow meter at the hydraulic motor to measure the volume flow and correct as required. 2. Damaged winch motor. Replace the winch motor.
J
Joel BakerAug 26, 2025
How to fix ROTZLER TITAN TI 5 Winches that cannot hold the load?
- J
  James VasquezAug 26, 2025
  How to fix ROTZLER Winches that cannot hold the load? This issue may arise due to: * Rope being wound onto the rope drum in the wrong rotation direction. To resolve this, wind the rope onto the winch in accordance with the assembly instruction, observing the correct rotation direction (CC or CW). * Using the wrong control valve, specifically one with no connection to the tank in the neutral position. Install a control valve with «H» or «Y» position in the neutral position. * Damaged sprag clutch assembly. Replace the damaged sprag clutch assembly.
