Roundup DCV-200 - Replacement Parts (continued); Parts List

15
Display Cabinet vertiCal
P/N 1011068 Rev. D 08/10
Item Part Description Qty.
No.
REPLACEMENT PARTS (continued)
1 0505924 Runner, Top Pan, Horizontal 1
2 0505923 Runner, Top Pan, Vertical 1
3 0021632 Top Heater Plate Weldment 1
4 0505897 Crumb Tray 1
5 0021637 Top Shelf Weldment 1
6 0505931 Guard, Top Shelf 1
7 0400354 Strain Relief 1
8 0700451 Power Cord 1
9 1001192 Label, Caution HOT 2
10 7000740 HeaterElementKit,375W120VAC 1
11 0505936 Heater Holding Strip, Top 2
12 0400402 Top Drawer Insulation 1
13 0505937 Heater Holding Strip, Top Short 2
14 0505935 Cover Plate, Top Heater 1
15 0012455 Light Holder Bracket Assembly 8
(Incl. 17, 57, & 66)
16 0021626 Light Shield Weldment 2
17 4060189 Lampholder, Quartz 8
18 0800415 Halogen Light Wire Guard 2
19 4060436 Halogen Bulb, 120V 100W 4
20 0021631 Bottom Heater Plate Weldment 1
21 0505896 Divider, Bottom Drawer 1
22 7000741 HeaterElementKit,975W120VAC 1
23 0505893 Heater Holding Strip, Bottom 2
24 0012486 Hi Limit Housing Assembly 1
25 5040270 Extrusion Base Hinge 1
26 7000743 FrontGlassReplacementKit 1
27 7000742 SideGlassReplacementKit(Incl.28) 2
28 1000998 Window Label, Caution HOT 2
29 7000458 Thermostat 1/2” Disc Automatic Reset 1
30 0400329 Rubber Grommet 2” Dia. 2
31 0021625 Lid Weldment 1
32 0200287 Top Cover Gasket, Silicone 1
33 0021634 Top Support Weldment 1
34 0021627 False Top Weldment 1
35 0021635 Flange, Back Door, Top Weldment 1
36 2100321 Upper Track, Back Door 1
37 7000745 RearDoorReplacementKit 2
38 308P123** Machine Screw #8-32 x 3/16” Lg. S/S 1
39 2100320 Lower Track, Back Door 1
40 0024636 Flange, Back Door, Bottom Weldment 1
41 7000136 TerminalBlock3-PoleKit 1
42 0505904 Channel, Wire 1
43 0021624 Support, Right Side Weldment 1
44 0021623 Support, Left Side Weldment 1
45 CON99- Terminal Block 7-Pin 1
0010
46 0021633 Cover, Back Electrical Panel Weldment 1
47 7000543 RockerSwitchKit,125VAC,RedIndicator 1
48 1001213 Label, Shock Hazard 1
49 1031039 Spec Label 1
50 7000345 Control,Temp.DisplayKit 1
51 1001037 Label, Control Panel 1
52 7000652 SolidStateRelayKit,ZeroCross,50A 1
53 4010199 Transformer, 120VAC 1
54 0505921 Bracket, Transformer and Relay 1
55 0400119 Bushing, Shorty 5/8” 1
56 310P196** Shoulder Bolt #10-32 x 1/8” Lg. 1
57 306P104** Machine Screw, #06-32 x 1/4” Lg. 1
58 308P143**Nut,HexKEPS#8-32Steel 1
59 306P123** Machine Screw #6-32 x 7/8” Lg. S/S 1
60 308P226** Machine Screw, Hex Slotted 1
#8-32 x 1/2” Lg. S/S
61 306P104** Machine Screw #6-32 x 1/4” Lg. S/S 1
62 304P105**Nut,HexKEPS#4-40 1
63 308P145** Nut, Hex Acorn #8-32 Low Crown S/S 1
64 310P134** Nut, Hex, Acorn #10-32 Low Crown S/S 1
65 308P181** Machine Screw, #8-32 x 3/8” Lg. S/S 1
66 308P104** Machine Screw #8-32 x 3/8” Lg. 1
67* 0400111 Bushing, Shorty 1/2” 2
68* 2120179 Spacer 1/4" x 1/4” 4
69* 306P130**Nut,HexKEPS#6-32ZincPlated 1
70* 308P102** Washer, Int Tooth #8 1
71* 308P151** Screw SEMS #8-32 x 5/16” Lg. 1
72* 308P103** Machine Screw #8-32 x 1/4” Lg. 1
73* 310P146**NutHexKEP#10-32 1
74* 310P180** Machine Screw #10-32 x 1 3/4” Lg. 1
75 0400404 Insulation, Elec. Panel 1
76 0505994 Heater Holding Strip, Front 1
77 212P148** Brass Spacer 2
78 4010229 Transformer, 56VA, 10V 1
79 3080223 Washer, Flat #8 1
80 0504680 Side Glass Latch, Left 1
81 0504679 Side Glass Latch, Right 1
Item Part Description Qty.
No.
* not shown
** only available in packages of 10
