Bulbs Wattage
Headlight dipped beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60/55
Headlight main beam . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Sidelights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Direction indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Side repeater lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Front fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Stop/tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21/5
Reversing lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Rear fog light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Number plate light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Engine compartment light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Interior courtesy lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 or 10
Map reading and courtesy light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Footwell and glovebox lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 or 5
Vanity mirror light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Luggage compartment light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Instrument panel illumination and warning lights . . . . . . . . . . . . . . . . . . 1.2
Ignition warning light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Switch illumination bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.36
Heater control illumination bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0.36 and 1.2
Chapter 12 Body electrical system
Airbag supplementary restraint system - general information . . . . . 26
Aerial amplifier - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . 22
Anti-theft system - general information . . . . . . . . . . . . . . . . . . . . . . . 24
Anti-theft system components - removal and refitting . . . . . . . . . . . 25
Battery - removal and refitting . . . . . . . . . . . . . . . . . . . . .See Chapter 5
Battery check, maintenance and charging . . . . . . . . . . .See Chapter 1
Bulbs (exterior lights) - renewal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Bulbs (interior lights) - renewal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Central control unit - description, removal and refitting . . . . . . . . . . 11
Clock - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Compact disc player - removal and refitting . . . . . . . . . . . . . . . . . . . 20
Electrical fault finding - general information . . . . . . . . . . . . . . . . . . . 2
Electrical system check . . . . . . . . . . . . . . . . . . . . . . . . . .See Chapter 1
Exterior light units - removal and refitting . . . . . . . . . . . . . . . . . . . . . 7
Fuses and relays - general information . . . . . . . . . . . . . . . . . . . . . . . 3
General information and precautions . . . . . . . . . . . . . . . . . . . . . . . . 1
Headlight beam alignment - checking and adjustment . . . . . . . . . . 8
Horn - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Instrument panel - removal and refitting . . . . . . . . . . . . . . . . . . . . . . 9
Instrument panel components - removal and refitting . . . . . . . . . . . 10
Power amplifier - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . 23
Radio/cassette player - removal and refitting . . . . . . . . . . . . . . . . . . 19
Speakers - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Switches - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Tailgate wiper motor and linkage - removal and refitting . . . . . . . . . 17
Trip computer - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . 13
Windscreen/tailgate and headlight washer system and
wiper blade check . . . . . . . . . . . . . . . . . . . . . . . . . . . .See Chapter 1
Windscreen/tailgate/headlight washer system components -
removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Windscreen wiper motor and linkage - removal and refitting . . . . . . 16
Wiper arms - removal and refitting . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12•1
