Lubrication
Engine oil type/specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See Chapter 1
Engine oil capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . See Chapter 1
Torque wrench settings Nm lbf ft
Cylinder head bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 50
Cylinder head side cover bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Timing belt cover bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Timing belt backplate bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Timing belt tensioner bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 32
Camshaft sprocket bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 24
Camshaft carrier bolts:
4 bolts at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
2 bolts at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 21
Oil gallery bolts:
8 bolts at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 21
2 bolts at . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Crankshaft pulley centre bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115 85
Driveplate bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75 55
Flywheel bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105 78
Filter head bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 16
Main bearing caps:
Bolts 1 to 8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 30
Bolts 9 to 16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68 50
Bolts 17 to 24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 37
Big-end bearing caps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 37
Oil cooler centre bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 37
Oil pump housing bolts:
M6 bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
M8 bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 16
Oil pick-up pipe bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Sump nuts and bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Rocker arm guide plate bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Inlet manifold retaining nuts and bolts . . . . . . . . . . . . . . . . . . . . . . . . . . 22 16
Exhaust manifold retaining nuts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 33
Exhaust manifold heat shield bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 9
Front engine mounting to transmission bracket . . . . . . . . . . . . . . . . . . . 80 59
Front engine mounting bracket to transmission . . . . . . . . . . . . . . . . . . . 40 30
Rear engine mounting bracket to transmission . . . . . . . . . . . . . . . . . . . 40 30
Right-hand engine mounting through-bolt . . . . . . . . . . . . . . . . . . . . . . . 45 33
Right-hand engine mounting to engine bracket . . . . . . . . . . . . . . . . . . . 60 44
Right-hand engine mounting bracket to engine . . . . . . . . . . . . . . . . . . . 25 18
Engine rear tie-bar to mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . . 75 55
Engine rear tie-bar mounting bracket bolts:
M10 bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 33
M12 bolts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 63
Engine rear tie-bar through-bolt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85 63
Longitudinal support member to underbody . . . . . . . . . . . . . . . . . . . . . 45 33
Engine snubber bracket to transmission . . . . . . . . . . . . . . . . . . . . . . . . 45 33
2B•2 V6 engine - in-car engine repair procedures
1380 Rover 800 Series Remake
1 General information
How to use this Chapter
1 This Part of Chapter 2 is devoted to repair
procedures possible while the engine is still
installed in the car, and includes only the
Specifications relevant to those procedures.
Since these procedures are based on the
assumption that the engine is installed in the
car, if the engine has been removed and
mounted on a stand, some of the preliminary
dismantling steps outlined will not apply.
2 Information concerning engine / trans-
mission removal and refitting, and engine
overhaul, can be found in Part C of this
Chapter, which also includes the
Specifications relevant to those procedures.
Engine description
3 The V6 engine fitted to Rover 825, 827 and
Sterling models is a water-cooled, six-
cylinder, four-stroke petrol engine, of single
overhead camshaft configuration per bank,
and 2494 cc (2.5 litre) or 2675 cc (2.7 litre)
capacity. The larger capacity being achieved
by an increase in cylinder bore diameter. The
2.5 litre engine was fitted to Rover 825 models
from 1986 until 1988, to be replaced by the
2.7 litre engine which is currently still in
production.
4 The combined crankcase and cylinder
block is of die-cast aluminium alloy
construction, and houses the pistons,
connecting rods and crankshaft. The solid
skirt cast aluminium alloy pistons have two
compression rings and an oil control ring, and
are retained on the connecting rods by semi-
floating gudgeon pins which are an
interference fit in the connecting rods. The
forged steel connecting rods are attached to
the crankshaft by renewable shell type big-
end bearings. The crankshaft is carried in four
main bearings, also of the renewable shell
type. Crankshaft endfloat is controlled by
thrust washers which are located on either
side of No 3 main bearing.
5 A single overhead camshaft is located in
