INFORMATION
TORQUE WRENCH SETTINGS 1REVISED: 12/96
Refer to the appropriate section heading for component torque figures, e.g.
Road wheel nuts - refer to SUSPENSION,
Exhaust front pipe to manifold - refer to MANIFOLD AND EXHAUST
GENERAL
Bolt M6 10 Nm...................................
Bolt M8 25 Nm...................................
Bolt M10 45 Nm..................................
Bolt M12 80 Nm..................................
1/4 UNC/UNF 9 Nm..............................
5/16 UNC/UNF 25 Nm.............................
3/8 UNC/UNF 40 Nm..............................
7/16 UNC/UNF 75 Nm.............................
1/2 UNC/UNF 90 Nm..............................
5/8 UNC/UNF 135 Nm..............................
ENGINE
Timing gear cover bolts 16 Nm.......................
Timing gear nuts 90 Nm............................
Timing chain tensioner bolts 22 Nm...................
Cylinder head nuts 34 Nm then a further 34 Nm...........................
Front cover plate bolts 11 Nm........................
Rocker shaft nuts 25 Nm............................
Camshaft thrust plate screws 11 Nm..................
Rocker cover bolts 5 Nm...........................
Crankshaft pulley bolt 150 Nm........................
Engine LH mounting:
Mounting to subframe - nuts 25 Nm..................
Mounting to engine - bolts 25 Nm....................
Engine RH mounting:
Mounting to flywheel housing cover - bolts 18 Nm.......
Mounting to subframe - nuts 22 Nm..................
Engine steady bar upper bolts 22 Nm..................
Engine steady bar lower:
Bar to subframe bolt 40 Nm........................
Bar to flywheel housing bolt 40 Nm...................
Oil pressure gauge sensor 60 Nm....................
Oil pressure relief valve cap 60 Nm...................
Oil pressure switch 25 Nm..........................
Oil pump to engine - bolts 11 Nm.....................
Flywheel housing to engine/gearbox - bolts 25 Nm.......
Earth lead to engine - bolt 10 Nm.....................
Engine to gearbox - nuts and bolts 8 Nm..............
Flywheel to crankshaft - bolt 150 Nm...................
Flywheel housing cover - bolts 10 Nm.................
Engine mounting adaptor plate to engine - bolts 25 Nm....
