INFORMATION
2
TORQUE WRENCH SETTINGS REVISED: 12/96
EMISSION CONTROL
Oil breather/separator to flywheel housing 18 Nm........
Catalytic converter to tail pipe nuts 9 Nm..............
Catalytic converter to front pipe nuts 45 Nm.............
Emission canister purge valve to body - bolts 9 Nm......
ENGINE MANAGEMENT SYSTEM
ECT sensor to thermostat housing 15 Nm..............
MAP sensor to inlet manifold 6 Nm...................
IAT sensor to inlet manifold 7 Nm....................
TP sensor to throttle body screws 1.5 Nm...............
Throttle housing to inlet mainifold - bolts 8 Nm..........
Throttle pedal nuts 25 Nm...........................
Spark plugs 25 Nm................................
Ignition coil to bracket - bolts 10 Nm...................
HO2S to exhaust manifold 55 Nm.....................
Air cleaner to inlet manifold 7 Nm....................
ECM to mounting bracket 10 Nm.....................
ECM mounting bracket to body 10 Nm.................
IACV to inlet manifold - bolts 7 Nm...................
CMP sensor to engine - bolt 10 Nm...................
CKP sensor to flywheel housing - bolts 6 Nm...........
CKP sensor multiplug to flywheel housing - bolt 3 Nm....
FUEL SYSTEM
Fuel breather valve nut 9 Nm.......................
Fuel pump to fuel tank nuts 9 Nm....................
IFS to bulkhead - screws 2 Nm......................
Fuel filter mounting bracket to body 9 Nm..............
Fuel pipe unions to fuel filter 30 Nm...................
Fuel feed/return pipes to fuel rail 5 Nm................
Fuel rail to inlet manifold - bolts 10 Nm.................
COOLING
Radiator brackets to bonnet platform 9 Nm.............
Thermostat housing bolts 11 Nm.....................
Coolant pump bolts 22 Nm..........................
Coolant pump pulley bolts 10 Nm.....................
Expansion tank to mounting bracket 10 Nm.............
Expansion tank mounting bracket to body 10 Nm.........
