INFORMATION
TORQUE WRENCH SETTINGS 3REVISED: 12/96
MANIFOLD AND EXHAUST
Front pipe to manifold nuts 22 Nm....................
Front pipe to differential housing 22 Nm................
Inlet and exhaust manifold nuts 22 Nm.................
Catalytic converter to tail pipe nuts 9 Nm..............
Catalytic converter to front pipe nuts 45 Nm.............
CLUTCH
Flywheel centre bolt 150 Nm..........................
Pressure plate to flywheel bolts 25 Nm.................
Flywheel housing to engine block bolts 25 Nm...........
Slave cylinder to mounting bracket 37 Nm..............
Slave cylinder mounting bracket to flywheel
housing:
M8 bolts 37 Nm..................................
M5 bolt 7 Nm...................................
Pipe union to master cylinder 14 Nm..................
Pipe union to slave cylinder 14 Nm....................
MANUAL GEARBOX
Gearbox to engine bolts 28 Nm......................
Third motion shaft bearing retaining bolts 18 Nm.........
First motion shaft gear nut 200 Nm.....................
Speedometer drive housing to gearbox - bolts 25 Nm.....
Speedometer drive housing cover - bolts 8 Nm.........
Speedometer drive pinion clamping plate - bolt 8 Nm.....
STEERING
Steering wheel nut 49 Nm...........................
Drivers air bag module Torx screws 9 Nm.............
Steering column upper mounting to fascia rail bolt 25 Nm..
Inner column to steering rack pinion clamp bolt 16 Nm....
Track rod ball joint to steering arm nut 30 Nm...........
Steering rack U-bolts 15 Nm.........................
Steering rack pinion cover bolts 15 Nm.................
Steering arm to front hub bolts 45 Nm.................
Steering column to pinion - bolt 15 Nm.................
