TORQUE WRENCH SETTINGS REVISED: 12/96
SUSPENSION
Wheel nuts:
Alloy wheels 50 Nm...............................
Steel wheels 60 Nm..............................
Upper arm to front hub 52 Nm.......................
Lower arm to front hub 52 Nm.......................
Front hub to drive shaft - nut 260 Nm...................
Front subframe turret bolts 67 Nm....................
Front damper to body bracket - nut 37 Nm..............
Front damper to upper arm - nut 48 Nm................
Front subframe to body - nuts and bolts 25 Nm..........
Rear damper to body 25 Nm.........................
Rear damper to suspension arm 25 Nm................
BRAKES
Bleed screw to caliper 9 Nm........................
Brake master cylinder nuts 25 Nm....................
Brake servo banjo bolt 50 Nm........................
Brake servo to bracket nuts 25 Nm....................
Brake servo bracket nuts and bolts to body 25 Nm........
Brake caliper to swivel hub bolts 52 Nm................
Brake disc to drive flange bolts 57 Nm.................
Brake drum back plate to radius arm bolts 28 Nm........
Pressure limiting valve to body bolt 17 Nm..............
Brake pipe to master cylinder - union 14 Nm............
Brake drum to hub - screw 7 Nm....................
Brake pipe union to pressure reducing valve 14 Nm.......
Pressure reducing valve to body - bolt 17 Nm...........
Brake pedal pivot bolt - nut 15 Nm....................
Brake light switch bracket to pedal box 5 Nm...........
Brake hose union to caliper 15 Nm....................
Brake pipe unon to wheel cylinder 14 Nm...............
RESTRAINT SYSTEMS
Rotary coupler bolts 15 Nm..........................
Diagnostic unit 9 Nm..............................
Airbag module screws 7 Nm........................
Diagnostic harness earth lead bolt 10 Nm..............
Front seat belt stalk bolt 32 Nm......................
Front seat belt upper mounting bolt 32 Nm..............
Front seat belt lower mounting bolt 30 Nm..............
Front seat belt upper mounting bolt 30 Nm..............
Seat belt pre-tensioner reel bolt 30 Nm.................
Seat belt pre-tensioner tube nut 6 Nm................
Seat belt pre-tensioner tube screw 1.2 Nm..............
Rear seat belt buckle to body - bolt 30 Nm..............
Rear seat belt reel to body - bolt 30 Nm................
Rear seat belt lower mounting bolt 30 Nm..............
Rear seat belt upper mounting bolt 30 Nm..............
