Wheel changing
152
Removing the spare wheel
Fully open the tailgate and hinge the rear
portion of the parcel shelf forward.
Unlatch and raise the loadspace floor panel
and then secure the panel in a raised position
by engaging the stay (as shown).
Using the wheel brace, remove the spare
wheel retaining nut. Pull the loop of the
webbing rearward; the wheel will be raised up
and lifted onto the rear tailgate.
NOTE: A warning triangle is stowed on the
underside of the loadspace floor panel (see
’Warning triangle’).
WARNING
The wheels are extremely heavy. Take care
when lifting and particularly when removing
the spare wheel from the loadspace.
