Bulb replacement
168
Rear courtesy & reading lights
Rear passenger courtesy light bulb: prise the
lens from the courtesy light unit, then pull the
bulb to remove.
Rear passenger reading light bulb: prise the
lens from the courtesy light unit (as above).
Unscrew both retaining screws and withdraw
light unit from the roof. The bulb can be
reached from the rear of the unit.
Rear footwell light
Prise the combined lens and holder assembly
from the rear of the centre console and
remove bulb from clips.
Replace the bulb then refit assembly to the
centre console.
High mounted stop light
Unclip the light cover from the inside of the
upper tailgate. Twist to release the bulb
holders, and pull to remove the bulbs.
