General data
180
APPROACH, DEPARTURE AND BREAKOVER ANGLES
NOTE: All figures are ride height figures for vehicles with 255/65 x16 tyres at curb weight, plus
the weight of a 165 lb (75 kg) driver and are given in degrees.
Front - approach angle
CRAWL & ACCESS LOW STANDARD HIGH
To bib spoiler* 24° 28° 31° 34°
To bumper 28° 32° 34° 38°
* It is recommended that the bib spoiler is removed for all serious off-road driving.
Rear - departure angle
CRAWL & ACCESS LOW STANDARD HIGH
To crossmember 24° 27° 29° 32°
Breakover angle
CRAWL & ACCESS LOW STANDARD HIGH
160° 156° 154° 151°
