ENEN
1918
CONTROL PANEL
FULL
(B)
(A) (C) (D) (E)
Power Control (A)
The power control turns the unit on and off. After switching the air conditioner off, you must wait 3
minutes before switching it back on again.
Warning Light “FULL (B)
Condensed water may accumulate in the unit.
If the internal tank becomes full, the warning light will come on and the unit will stop operating until
the unit has been drained (evacuation #9). To drain the unit, refer to storage instructions p.2.
Timer (C)
Auto turn OFF : with the machine in running mode, press the timer button. Then set the desired wor-
king time in hours before shut down by pressing the “+” or “-” buttons.
Auto turn ON: With the machine in OFF mode, press the timer button. Then set the desired time de-
lay ON in hours by pressing the “+” or “-” buttons before the unit automatically starts running in the
latest used mode.
The time is adjustable between 1 to 24hours
Mode Control (D)
The mode control has four settings. A light indicates which mode is currently being used.
Cooling mode
: During the cooling mode the air is cooled and hot air is expelled through the
heat exhaust hose (#12). Adjust fan speed and air temperature to suit your desired comfort level.
Use the buttons (-) and (+) to set the desired temperature between 16 and 32°C. After 10 seconds
the display will revert to room temperature.
Note: the air exchange hoses must vent outside the room when using cooling mode.
Eco mode
: In this mode, the targeted temperature is automatically set up -3°C vs the room
temperature to save energy. The speed is automatically defined. After 3 seconds the display will
revert to room temperature.
Dehumidify mode
: Air is dehumidified as it passes through the unit, without being in full
cooling mode. In this mode, If temperature is higher than 25°C, fan speed can be adjusted;
otherwise, fan speed is fixed to “low”.
In this mode, do not connect the exhaust hose and let the warm air return to the room. You will
need to drain the unit to evacuate the water : refer to storage instructions p.2. for installation.
Fan Mode
: air is circulated throughout the room with no cooling. The air exchange hose does
not need to be installed in this mode Adjust fan speed to suit your desired comfort level.
Fan Speed Control (E)
The fan speed control has three settings: High, Medium and Low.
Remote control
The remote control uses 2 x AAA or LR03 1.5V batteries which are not included.
To change the remote’s battery, remove the cover on the back of the remote controller and insert
batteries with the (+) and (-) poles pointing in the proper direction.
Remove the batteries if the remote control is not used for a month or longer.
Remote control operations are identical to the functions on the control panel. Please take care not to
scratch or damage the transmitter (LED) located on the end of the remote control as this will impair
its proper operation.
TROUBLESHOOTING
Trouble Analysis
The appliance does not start - Please wait 3 minutes and start again,
protector device may be preventing unit from
working.
- The plug is not properly plugged.
The appliance stops running during operation - Set temperature is too high.
- Air outlets are blocked by obstacles or hose is
obstructed
- Air inlets (filter) are blocked by dust
The appliance does not run and water full indi-
cator is lit
- Water needs to be drained : please refer to
paragraph “control panel – B”
- Drainage hose is obstructed or twisted
LEDs display “E1” or “E2” - Please refer to a specific Approved Service
Centre.
SHOULD A PROBLEM ARISE
Never dismantle the appliance yourself because R290 gas requires specific agreement for repairing.
A poorly repaired appliance may be dangerous for the user.
Do not use the appliance and contact a specific Approved Service Centre if:
The appliance has broken.
Unit or its power cord is damaged,
If your appliance does not work properly.
You can find a list of specific Approved Service Centres on Rowenta website.
HELP PROTECT THE ENVIRONMENT!
Your appliance contains valuable materials which can be recovered or recycled.
Leave it at a waste collection point or an approved service centre so that it can be disposed of
correctly.
Do not throw away the batteries with your household waste : instead, bring them to anyone
of the special battery collection points.
These instructions can also be found on our internet site www.rowenta.com
