R+M Suttner ST-2300 - Technical Specification; CE Labelling and Standards

User Manual ST-2300
Product Code.: 20 2300 556
Suttner GmbH, Hauptstraße 15-17, 33818 Leopoldshöhe
Tel.: +49(0)5208 - 91 46 - 0, Fax: +49(0)5208 - 91 46 - 15
www.rm-suttner.com, Email: info@rm-suttner.com
4
Ver. 1.0
When spraying sensitive surfaces (e.g. vehicle tyres, painted surfaces) damage may occur. For sensitive surfaces do not
use any fine needle jets and maintain a minimum jet spray distance. The minimum jet spray distance depends on the
pressure and the surface to be cleaned.
CE labelling and standards
CE labelling and standardsCE labelling and standards
CE labelling and standards
The spray gun meets the requirements of DIN EN 60355-2-79 (from 350 bar upwards DIN EN 1829). Due to its low
volume the spray gun - when used with Group II fluids - comes under Article 3 Paragraph 3 of Pressure Equipment
Directive 97/23 EC. Accordingly the spray gun must be designed and manufactured in accordance with "good
engineering practice" and is exempt from CE labelling. No CE label may be attached or any Declaration of Conformity
issued.
Technical Specification
Technical SpecificationTechnical Specification
Technical Specification
Maximum permissable pressure 310 bar / 31,0 MPA / 4500 PSI
Minimum pressure 10 bar / 1,0 MPa
Recommended pressure 280 bar / 28,0 MPa
Maximum flow rate 45 l/min
Temperature 5 - 150 °C
Jet nozzle size min. 020
Input connector Swivel M22x1,5 AG
Outlet connector G1/4 IG
Weight ca. 1,0 kg
Abkürzungen und Symbole
Abkürzungen und SymboleAbkürzungen und Symbole
Abkürzungen und Symbole
FT, MT Female thread, male thread
G Withworth-pipe thread to DIN ISO 228, identical BSP = British Standard Pipe
NPT National Pipe Thread, American standard thread
Die in dieser Betriebsanleitung angegebenen Einsatzgrenzen für Druck, Temperatur und Medien sind in Tests ermittelte
Maximalwerte. Im Einsatz muss berücksichtigt werden, dass aufgrund der wechselseitigen Beeinflussung der
Betriebsparameter die Maximalwerte entsprechend niedriger anzusetzen sind. Das dauerhafte Arbeiten unter
Maximallastung kann die Lebensdauer der Spritzpistole verkürzen
