RSG UNIVERSAL CONTROLLER PLUS User Manual

Industry Standard
Switching Options
MAXIPLUS SWITCH UNIT
UNI-MAXF/MXH-XXX
MEGA SWITCH UNIT UNI-MUL-XXX
MINI SWITCH UNIT UNI-MIN-XXX
Universal Multi-Way Switching Options
System
Connector
Diagnostic
Reset
Can BUS
Connector
Inputs
12 x Positive Inputs
Software configured
12 x Negative Inputs
Software Configured
Audio Inputs
USB Port
RS485
MAXI SWITCH UNIT UNI-MAX-XXX
Traditional Individual
Switching Options
MIDI SWITCH UNIT UNI-MID-XXX
SLIMLINE SWITCH UNIT UNI-SLM-XXX
MAXIPLUS SWITCH UNIT UNI-MAXF/MXH-XXX
Microphone
Option
RSG Engineering Limited Telephone : 01543 438800 Fax : 01543 438801 Email : sales@rsg-ontop.com Web : www.rsg-ontop.com
1:7
UNIVERSAL CONTROLLER PLUS (MCS-32) USER GUIDE V3 F : CONNECTION AND SWITCH DETAILS
F:2 Inputs and switching options
F : Connection and Switch Details

RSG UNIVERSAL CONTROLLER PLUS Specifications
